| Nombor Bahagian | YXD090TN02-40NM01 |
| Jenama | SEBO |
| Saiz | 9.0 |
| Permohonan | PAD |
| Resolusi | 1280×800 |
| Komposisi | LCM |
| Kecerahan | 250 |
| CR | 700:1 |
| Warna | 16.7M |
| Lampu latar | WLED |
| Antara muka | LVDS |
| jenama panel | SEBO |
| model panel | YXD090TN02-40NM01 |
| jenis panel | a-Si TFT-LCD , LCM |
| saiz panel | 9.0 inch |
| resolusi | 1280(RGB)×800 , WXGA |
| mod paparan | TN, Normally White, Transmissive |
| kawasan aktif | 193.92×121.2 mm |
| garis besar | 206.76×135.06×3.9 mm |
| permukaan | Hard coating |
| kecerahan | 250 cd/m² (Typ.) |
| nisbah kontras | 700:1 (Typ.) |
| warna paparan | 16.7M (8-bit) |
| masa tindak balas | 10/15 (Typ.)(Tr/Td) |
| sudut pandangan | 70/70/70/50 (Typ.)(CR≥10)(L/R/U/D) |
| kekerapan | 60Hz |
| jenis lampu | WLEDWithout Driver |
| antara muka isyarat | LVDS (1 ch, 8-bit), 40 pins |
| voltan masukan | 3.3/11/20/-6.8V (Typ.)(DVDD/AVDD/VGH/VGL) |
| permohonan | PAD |
