| Nombor Bahagian | LTA090B230F |
| Jenama | TOSHIBA |
| Saiz | 9.0 |
| Permohonan | IA |
| Resolusi | 536×328 |
| Komposisi | LCM |
| Kecerahan | 480 |
| CR | 250:1 |
| Warna | 262K |
| Lampu latar | CCFL |
| Antara muka | TTL |
| jenama panel | Toshiba Matsushita |
| model panel | LTA090B230F |
| jenis panel | a-Si TFT-LCD , LCM |
| saiz panel | 9.0 inch |
| resolusi | 536(RGB)×328 |
| mod paparan | TN, Normally White, Transmissive |
| kawasan aktif | 196.18×120.05 mm |
| garis besar | 212.2×135.2 mm |
| permukaan | Clear |
| kecerahan | 480 cd/m² (Typ.) |
| nisbah kontras | 250:1 (Typ.) |
| warna paparan | 262K (6-bit) |
| masa tindak balas | 70/40 (Max.)(Tr/Td) |
| sudut pandangan | 80/80/45/80 (Typ.)(CR≥10)(L/R/U/D) |
| jenis lampu | 1 pcsCCFLWithout Driver |
| antara muka isyarat | Parallel RGB (1 ch, 6-bit), 30 pins |
| voltan masukan | 3.3V (Typ.) |
| permohonan | IA |
