| Nombor Bahagian | TM090JDH01 |
| Jenama | Tianma |
| Saiz | 9.0 |
| Permohonan | PAD |
| Resolusi | 1280×800 |
| Komposisi | LCM |
| Kecerahan | 250 |
| CR | 700:1 |
| Warna | 262K/16.7M |
| Lampu latar | WLED |
| Antara muka | LVDS |
| jenama panel | TIANMA |
| model panel | TM090JDH01 1 Compatible model |
| jenis panel | a-Si TFT-LCD , LCM |
| saiz panel | 9.0 inch |
| resolusi | 1280(RGB)×800 , WXGA |
| mod paparan | TN, Normally White, Transmissive |
| kawasan aktif | 193.92×121.2 mm |
| garis besar | 206.76×135.06×4.8 mm |
| permukaan | |
| kecerahan | 250 cd/m² (Typ.) |
| nisbah kontras | 700:1 (Typ.) |
| warna paparan | 262K/16.7M (6-bit / 6-bit + Hi-FRC), CIE193170% |
| masa tindak balas | 25 (Typ.)(Tr+Td) |
| sudut pandangan | 70/70/70/50 (Typ.)(CR≥10)(L/R/U/D) |
| kekerapan | 60Hz |
| jenis lampu | 3S12PWLEDWithout Driver |
| antara muka isyarat | LVDS (1 ch, 6/8-bit), 51 pins |
| voltan masukan | 3.3/11/20/-6.8V (Typ.)(VCC/AVDD/VGH/VGL) |
| permohonan | PAD |
