AUO B101UAN07.2 lembaran data, spesifikasi, stok, aplikasi www.looklcd-my.com
LookLCD LookLCD


B101UAN07.2

B101UAN07.2
B101UAN07.2
B101UAN07.2 thumb B101UAN07.2 thumb
Jenama
AUO
Saiz
10.1
Permohonan
PAD
Resolusi
1200×1920
Komposisi
LCM
Kecerahan
400
CR
1000:1
Warna
16.7M
Lampu latar
WLED
Antara muka
MIPI
In Stock
19103
Spesifikasi

Nombor Bahagian B101UAN07.2
JenamaAUO
Saiz10.1
PermohonanPAD
Resolusi1200×1920
KomposisiLCM
Kecerahan400
CR1000:1
Warna16.7M
Lampu latarWLED
Antara mukaMIPI
jenama panelAUO
model panelB101UAN07.2
jenis panel a-Si TFT-LCD , LCM
saiz panel10.1 inch
resolusi1200(RGB)×1920 , WUXGA
mod paparanAHVA, Normally Black, Transmissive
kawasan aktif135.36×216.576 mm
garis besar143×227.93×4.3 mm
permukaanGlare (Haze 0%), Hard coating
kecerahan400 cd/m² (Typ.)
nisbah kontras1000:1 (Typ.)
warna paparan16.7M (8-bit), CIE193171%
masa tindak balas25 (Typ.)(Tr+Td)
sudut pandangan85/85/85/85 (Typ.)(CR≥10)(L/R/U/D)
kekerapan60Hz
jenis lampu8S4PWLEDWithout Driver
antara muka isyaratMIPI (4 data lanes), 45 pins
voltan masukan3.3V (Typ.)
permohonanPAD
