| Nombor Bahagian | HSD090ICW1-A00 |
| Jenama | HannStar |
| Saiz | 9.0 |
| Permohonan | DPF |
| Resolusi | 640×234 |
| Komposisi | LCM |
| Kecerahan | 250 |
| CR | 500:1 |
| Warna | |
| Lampu latar | WLED |
| Antara muka | Analog |
| jenama panel | HannStar |
| model panel | HSD090ICW1-A00 |
| jenis panel | a-Si TFT-LCD , LCM |
| saiz panel | 9.0 inch |
| resolusi | 640(RGB)×234 |
| mod paparan | TN, Normally White, Transmissive |
| kawasan aktif | 197.76×111.735 mm |
| garis besar | 210.7×126.4×4.25 mm |
| permukaan | |
| kecerahan | 250 cd/m² (Typ.) |
| nisbah kontras | 500:1 (Typ.) |
| warna paparan | , CIE193145% |
| masa tindak balas | 25 (Typ.)(Tr+Td) |
| sudut pandangan | 70/70/65/65 (Typ.)(CR≥10)(L/R/U/D) |
| jenis lampu | 3S8PWLEDWithout Driver |
| antara muka isyarat | TFT Specific Analog RGB, 26 pins |
| voltan masukan | 3.3/5/15/-10V (Typ.)(DVDD/AVDD/VGH/VGL) |
| permohonan | DPF |
