| Nombor Bahagian | LQ097L1JY01A |
| Jenama | SHARP |
| Saiz | 9.7 |
| Permohonan | PAD |
| Resolusi | 2048×1536 |
| Komposisi | LCM |
| Kecerahan | 440 |
| CR | 1000:1 |
| Warna | 16.7M |
| Lampu latar | WLED |
| Antara muka | eDP |
| jenama panel | SHARP |
| model panel | LQ097L1JY01A |
| jenis panel | IGZO TFT-LCD , LCM |
| saiz panel | 9.7 inch |
| resolusi | 2048(RGB)×1536 , QXGA |
| mod paparan | O-mode FFS, Normally Black, Transmissive |
| kawasan aktif | 196.608×147.456 mm |
| permukaan | Glare (Haze 0%), Hard coating (2H), Reflection 1.45% (Max.) |
| kecerahan | 440 cd/m² (Typ.) |
| nisbah kontras | 1000:1 (Typ.) |
| warna paparan | 16.7M (8-bit), CIE193172% |
| masa tindak balas | |
| sudut pandangan | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| kekerapan | 60Hz |
| jenis lampu | 7S6P×2CNWLEDWithout Driver |
| antara muka isyarat | eDP (4 Lanes), 56 pins |
| voltan masukan | 3.3V (Typ.) |
| permohonan | PAD |
| AM-1024768M2TMQW-T00H | AMPIRE | 9.7 | 1024×768 |
| BF097XN | Innolux | 9.7 | 1024×768 |
| BI097XN02 V.Y | Innolux | 9.7 | 1024×768 |
| LP097QX1-SPC3 | LG Display | 9.7 | 2048×1536 |
| LP097QX2-SPAV | LG Display | 9.7 | 1536×2048 |
| LP097X02-SLN1 | LG Display | 9.7 | 1024×768 |
| LQ097L1JY01 | SHARP | 9.7 | 2048×1536 |
| LQ097L1JY01A | SHARP | 9.7 | 2048×1536 |
| LQ097L1JY02Z | SHARP | 9.7 | 2048×1536 |
| TM097TDH02 | Tianma | 9.7 | 1024×768 |
| B101EAN01.5 | AUO | 10.1 | 1280×800 |
| B101UAN01.7 HW0A | AUO | 10.1 | 1920×1200 |
| CLAA101FP05 | CPT | 10.1 | 1920×1200 |
| CLAA101FP05 XG | CPT | 10.1 | 1920×1200 |
| LD070WX4-SM01 | LG Display | 7.0 | 800×1280 |
| LQ101R1SX01A | SHARP | 10.1 | 2560×1600 |
| LTN121AP05-302 | Samsung | 12.1 | 1280×800 |
| M070SW46 R0 | IVO | 7.0 | 1200×1920 |
| N101ICE-G62 | Innolux | 10.1 | 1280×800 |
| VVX10F034N00 | Panasonic | 10.1 | 1920×1200 |
