| Nombor Bahagian | L5S30883P00 |
| Jenama | SANYO |
| Saiz | 4.5 |
| Permohonan | CNS |
| Resolusi | 480×240 |
| Komposisi | LCM |
| Kecerahan | 400 |
| CR | 300:1 |
| Warna | 262K |
| Lampu latar | WLED |
| Antara muka | TTL |
| jenama panel | SANYO |
| model panel | L5S30883P00 |
| jenis panel | a-Si TFT-LCD , LCM |
| saiz panel | 4.5 inch |
| resolusi | 480(RGB)×240 , WQVGA |
| mod paparan | TN, Normally White, Transmissive |
| kawasan aktif | 99.36×56.04 mm |
| garis besar | 112.7×70.2 mm |
| permukaan | Glare (Haze 0%) |
| kecerahan | 400 cd/m² (Typ.) |
| nisbah kontras | 300:1 (Typ.) |
| warna paparan | 262K (6-bit) |
| masa tindak balas | 10/20 (Typ.)(Tr/Td) |
| sudut pandangan | 55/55/45/55 (Typ.)(CR≥10)(L/R/U/D) |
| kekerapan | 60Hz |
| jenis lampu | WLEDEmbedded (LED Driver) |
| antara muka isyarat | Parallel RGB (1 ch, 6-bit), 40 pins |
| voltan masukan | 3.3V (Typ.) |
| rohs: | |
| permohonan | CNS |
