| Nombor Bahagian | TM045XDZP08 |
| Jenama | Tianma |
| Saiz | 4.5 |
| Permohonan | MPH |
| Resolusi | 540×960 |
| Komposisi | LCM |
| Kecerahan | 350 |
| CR | 800:1 |
| Warna | 16.7M |
| Lampu latar | WLED |
| Antara muka | MIPI |
| jenama panel | TIANMA |
| model panel | TM045XDZP08 |
| jenis panel | a-Si TFT-LCD , LCM |
| saiz panel | 4.5 inch |
| resolusi | 540(RGB)×960 , qHD |
| mod paparan | IPS, Normally Black, Transmissive |
| kawasan aktif | 55.485×98.64 mm |
| garis besar | 60.71×109.1 mm |
| permukaan | |
| kecerahan | 350 cd/m² (Typ.) |
| nisbah kontras | 800:1 (Typ.) |
| warna paparan | 16.7M (8-bit), CIE193170% |
| masa tindak balas | 25 (Typ.)(Tr+Td) |
| sudut pandangan | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| kekerapan | 60Hz |
| jenis lampu | 10S1PWLEDWithout Driver |
| antara muka isyarat | MIPI (2 data lanes), 25 pins |
| voltan masukan | 1.8/2.8V (Typ.)(IOVCC/VDD) |
| permohonan | MPH |
