| Nombor Bahagian | HT12X12-100 |
| Jenama | HYDIS |
| Saiz | 12.1 |
| Permohonan | NBPC |
| Resolusi | 1024×768 |
| Komposisi | LCM |
| Kecerahan | 150 |
| CR | 200:1 |
| Warna | 262K |
| Lampu latar | CCFL |
| Antara muka | LVDS |
| jenama panel | HYUNDAI |
| model panel | HT12X12-100 |
| jenis panel | a-Si TFT-LCD , LCM |
| saiz panel | 12.1 inch |
| resolusi | 1024(RGB)×768 , XGA |
| mod paparan | TN, Normally White, Transmissive |
| kawasan aktif | 245.76×184.32 mm |
| garis besar | 261×199×5.5 mm |
| permukaan | |
| kecerahan | 150 cd/m² (Typ.) |
| nisbah kontras | 200:1 (Typ.) |
| warna paparan | 262K (6-bit) |
| masa tindak balas | 50 (Typ.)(Tr+Td) |
| sudut pandangan | 45/45/15/30 (Typ.)(CR≥10)(L/R/U/D) |
| kekerapan | 60Hz |
| jenis lampu | 1 pcsCCFLWithout Driver |
| antara muka isyarat | LVDS (1 ch, 6-bit), 20 pins |
| voltan masukan | 3.3V (Typ.) |
| permohonan | NBPC |
| AA121TD02 | Mitsubishi | 12.1 | 1280×800 |
| HT12X12-100 | HYDIS | 12.1 | 1024×768 |
| HT12X21-220 | HYDIS | 12.1 | 1024×768 |
| HT12X21-221 | HYDIS | 12.1 | 1024×768 |
| HT12X21-230 | HYDIS | 12.1 | 1024×768 |
| HT12X21-240 | HYDIS | 12.1 | 1024×768 |
| HT12X21-351 | HYDIS | 12.1 | 1024×768 |
| LQ121S1LG45 | SHARP | 12.1 | 800×600 |
| LQ12S41 | SHARP | 12.1 | 800×600 |
| PD121XL3 | E Ink | 12.1 | 1024×768 |
| B133XW01 V3 | AUO | 13.3 | 1366×768 |
| B141EW04 V5 | AUO | 14.1 | 1280×800 |
| B154EW02 V3 | AUO | 15.4 | 1280×800 |
| B154EW04 V7 | AUO | 15.4 | 1280×800 |
| HT141WXB-100 | BOE | 14.1 | 1280×800 |
| LTD121EX1S | TOSHIBA | 12.1 | 1280×768 |
| LTN140AT07-401 | Samsung | 14.0 | 1366×768 |
| LTN154X9-L02 | Samsung | 15.4 | 1280×800 |
| LTN156AT19-W01 | Samsung | 15.6 | 1366×768 |
| NT156WHM-N12 | BOE | 15.6 | 1366×768 |
