| Nombor Bahagian | HT141WXB-100 |
| Jenama | BOE |
| Saiz | 14.1 |
| Permohonan | NBPC |
| Resolusi | 1280×800 |
| Komposisi | LCM |
| Kecerahan | 230 |
| CR | 500:1 |
| Warna | 262K |
| Lampu latar | CCFL |
| Antara muka | LVDS |
| jenama panel | BOE |
| model panel | HT141WXB-100 18 Compatible model |
| jenis panel | a-Si TFT-LCD , LCM |
| saiz panel | 14.1 inch |
| resolusi | 1280(RGB)×800 , WXGA |
| mod paparan | TN, Normally White, Transmissive |
| kawasan aktif | 303.36×189.6 mm |
| garis besar | 319.5×205.5×5.5 mm |
| gaya bentuk | Wedge (PCBA Bent, Depth ≥5.2mm) |
| permukaan | Glare (Haze 0%), Hard coating (3H) |
| kecerahan | 230 cd/m² (Typ.) |
| nisbah kontras | 500:1 (Typ.) |
| warna paparan | 262K (6-bit) |
| masa tindak balas | 8 (Typ.)(Tr+Td) |
| sudut pandangan | 45/45/20/45 (Typ.)(CR≥10)(L/R/U/D) |
| kekerapan | 60Hz |
| jenis lampu | 1 pcsCCFLWithout Driver |
| antara muka isyarat | LVDS (1 ch, 6-bit), 30 pins |
| voltan masukan | 3.3V (Typ.) |
| permohonan | NBPC |
| B141EW04 V6 | AUO | 14.1 | 1280×800 |
| HT141WXB-100 | BOE | 14.1 | 1280×800 |
| HT14X13-101 | HYDIS | 14.1 | 1024×768 |
| HT14X13-102 | HYDIS | 14.1 | 1024×768 |
| LP141WP2-TPA1 | LG Display | 14.1 | 1440×900 |
| LP141WX3-TLA4 | LG Display | 14.1 | 1280×800 |
| LTN141AT12-J01 | Samsung | 14.1 | 1280×800 |
| LTN141AT16-B03 | Samsung | 14.1 | 1280×800 |
| LTN141W1-L09 | Samsung | 14.1 | 1280×800 |
| N141X6-L01 | Innolux | 14.1 | 1024×768 |
| HN133WU1-100 | BOE | 13.3 | 1920×1080 |
| LP171WU1-TLA7 | LG Display | 17.1 | 1920×1200 |
| LT121SL-105 | Samsung | 12.1 | 800×600 |
| LTD121EW6S | TOSHIBA | 12.1 | 1280×800 |
| LTM12C318S | TOSHIBA | 12.1 | 1024×768 |
| LTN141BT08-002 | Samsung | 14.1 | 1440×900 |
| LTN154AT12-D01 | Samsung | 15.4 | 1280×800 |
| LTN184KT02-T01 | Samsung | 18.4 | 1680×945 |
| N140B6-L02 | Innolux | 14.0 | 1366×768 |
| N150P5-L02 | Innolux | 15.0 | 1400×1050 |
