| Nombor Bahagian | LQ12S41 |
| Jenama | SHARP |
| Saiz | 12.1 |
| Permohonan | IA |
| Resolusi | 800×600 |
| Komposisi | LCM |
| Kecerahan | 270 |
| CR | 150:1 |
| Warna | 262K |
| Lampu latar | CCFL |
| Antara muka | TTL |
| jenama panel | SHARP |
| model panel | LQ12S41 |
| jenis panel | a-Si TFT-LCD , LCM |
| saiz panel | 12.1 inch |
| resolusi | 800(RGB)×600 , SVGA |
| mod paparan | TN, Normally White, Transmissive |
| kawasan aktif | 246×184.5 mm |
| garis besar | 290×225×13.7 mm |
| permukaan | Antiglare (Haze 28%), Hard coating (3H) |
| kecerahan | 270 cd/m² (Typ.) |
| nisbah kontras | 150:1 (Min.) |
| warna paparan | 262K (6-bit) |
| masa tindak balas | 20/40 (Typ.)(Tr/Td) |
| sudut pandangan | 70/70/55/55 (Min.)(CR≥5)(L/R/U/D) |
| jenis lampu | 2 pcsCCFLWithout Driver |
| antara muka isyarat | Parallel RGB (1 ch, 6-bit), 41 pins |
| voltan masukan | 3.3V (Typ.)(VCC) |
| permohonan | IA |
