| Nombor Bahagian | PD121XL3 |
| Jenama | E Ink |
| Saiz | 12.1 |
| Permohonan | IA |
| Resolusi | 1024×768 |
| Komposisi | LCM |
| Kecerahan | 1700 |
| CR | 800:1 |
| Warna | 262K |
| Lampu latar | WLED |
| Antara muka | LVDS |
| jenama panel | PVI |
| model panel | PD121XL3 |
| jenis panel | a-Si TFT-LCD , LCM |
| saiz panel | 12.1 inch |
| resolusi | 1024(RGB)×768 , XGA |
| mod paparan | TN, Normally White, Transmissive |
| kawasan aktif | 245.76×184.32 mm |
| garis besar | 263.5×204×26.3 mm |
| permukaan | Antiglare, Hard coating |
| kecerahan | 1700 cd/m² (Typ.) |
| nisbah kontras | 800:1 (Typ.) |
| warna paparan | 262K (6-bit) |
| masa tindak balas | 10/20 (Typ.)(Tr/Td) |
| sudut pandangan | 70/70/70/50 (Typ.)(CR≥10)(L/R/U/D) |
| kekerapan | 60Hz |
| jenis lampu | 14S4PWLEDWithout Driver |
| antara muka isyarat | LVDS (1 ch, 6-bit), 20 pins |
| voltan masukan | 3.3V (Typ.) |
| permohonan | IA |
