| Nombor Bahagian | B154EW04 V7 |
| Jenama | AUO |
| Saiz | 15.4 |
| Permohonan | NBPC |
| Resolusi | 1280×800 |
| Komposisi | LCM |
| Kecerahan | 165 |
| CR | 350:1 |
| Warna | 262K |
| Lampu latar | CCFL |
| Antara muka | LVDS |
| jenama panel | AUO |
| model panel | B154EW04 V7 1 Compatible model |
| jenis panel | a-Si TFT-LCD , LCM |
| saiz panel | 15.4 inch |
| resolusi | 1280(RGB)×800 , WXGA |
| mod paparan | TN, Normally White, Transmissive |
| kawasan aktif | 331.2×207 mm |
| gaya bentuk | Wedge (PCBA Bent, Depth ≥5.2mm) |
| permukaan | Glare (Haze 0%), Hard coating (3H), Antireflection |
| kecerahan | 165 cd/m² (Typ.) |
| nisbah kontras | 350:1 (Typ.) |
| warna paparan | 262K (6-bit) |
| masa tindak balas | 8/17 (Typ.)(Tr/Td) |
| sudut pandangan | 40/40/10/30 (Typ.)(CR≥10)(L/R/U/D) |
| kekerapan | 60Hz |
| jenis lampu | 1 pcsCCFLEmbedded (Inverter) |
| antara muka isyarat | LVDS (1 ch, 6-bit), 30 pins |
| voltan masukan | 3.3V (Typ.) |
| rohs: | |
| permohonan | NBPC |
| B154EW01 V1 | AUO | 15.4 | 1280×800 |
| B154EW01 VC | AUO | 15.4 | 1280×800 |
| B154EW02 V1 | AUO | 15.4 | 1280×800 |
| B154EW02 V3 | AUO | 15.4 | 1280×800 |
| B154EW02 V7 | AUO | 15.4 | 1280×800 |
| B154EW03 V1 | AUO | 15.4 | 1280×800 |
| B154EW04 V7 | AUO | 15.4 | 1280×800 |
| B154EW08 V0 HW2A | AUO | 15.4 | 1280×800 |
| B154EW09 V0 | AUO | 15.4 | 1280×800 |
| B154EW09 V1 | AUO | 15.4 | 1280×800 |
| AA121SJ23 | Mitsubishi | 12.1 | 800×600 |
| LP140WD1-TLM1 | LG Display | 14.0 | 1600×900 |
| LP173WF1-TLC1 | LG Display | 17.3 | 1920×1080 |
| LT121S1-153 | Samsung | 12.1 | 800×600 |
| LTM09C362 | TOSHIBA | 8.9 | 1024×600 |
| LTN141AT16-003 | Samsung | 14.1 | 1280×800 |
| LTN150PF-L03 | Samsung | 15.0 | 1400×1050 |
| LTN156AT01-B02 | Samsung | 15.6 | 1366×768 |
| N116HSE-EBC | Innolux | 11.6 | 1920×1080 |
| N140BGE-L41 | Innolux | 14.0 | 1366×768 |
