| Nombor Bahagian | DLC0270CUOF |
| Jenama | Other |
| Saiz | 2.7 |
| Permohonan | |
| Resolusi | 256×64 |
| Komposisi | OLED |
| Kecerahan | 100 |
| CR | 10000:1 |
| Warna | Mono(White) |
| Lampu latar | self |
| Antara muka | CPU/SPI |
| jenama panel | DLC |
| model panel | DLC0270CUOF 1 Compatible model |
| jenis panel | PM-OLED , OLED |
| saiz panel | 2.7 inch |
| resolusi | 256×64 |
| kawasan aktif | 66.53×16.61 mm |
| garis besar | 82×25.5×1.6 mm |
| permukaan | |
| kecerahan | 100 cd/m² (Typ.) |
| nisbah kontras | 10000 : 1 (Min.) |
| warna paparan | Mono(White) |
| sudut pandangan | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| kekerapan | 100Hz |
| ic pemandu | COF Built-in SSD1322UR1 |
| antara muka isyarat | 8-bit 6800/8080 parallel, 3/4-wire SPI, 30 pins |
