| Nombor Bahagian | DLC0283FZG-7 |
| Jenama | Other |
| Saiz | 2.8 |
| Permohonan | MPH |
| Resolusi | 240×320 |
| Komposisi | LCM |
| Kecerahan | 300 |
| CR | 400:1 |
| Warna | 262K |
| Lampu latar | WLED |
| Antara muka | CPU/RGB |
| jenama panel | DLC |
| model panel | DLC0283FZG-7 |
| jenis panel | a-Si TFT-LCD , LCM |
| saiz panel | 2.8 inch |
| resolusi | 240(RGB)×320 , QVGA |
| mod paparan | TN, Normally White, Transmissive |
| kawasan aktif | 43.2×57.6 mm |
| garis besar | 50×70 mm |
| permukaan | |
| kecerahan | 300 cd/m² (Typ.) |
| nisbah kontras | 400:1 (Typ.) |
| warna paparan | 262K , CIE193150% |
| masa tindak balas | 25 (Typ.)(Tr+Td) |
| sudut pandangan | 60/60/60/45 (Typ.)(CR≥10)(L/R/U/D) |
| kekerapan | 60Hz |
| jenis lampu | 5S1PWLEDWithout Driver |
| antara muka isyarat | CPU/RGB, 39 pins |
| voltan masukan | 1.8/2.8V (Typ.)(IOVCC/VCC) |
| permohonan | MPH |
