| Nombor Bahagian | DLC0240ACOG-3 |
| Jenama | Other |
| Saiz | 2.4 |
| Permohonan | HHP |
| Resolusi | 240×320 |
| Komposisi | OLED |
| Kecerahan | 100 |
| CR | |
| Warna | 16.7M |
| Lampu latar | self |
| Antara muka | CPU |
| jenama panel | DLC |
| model panel | DLC0240ACOG-3 |
| jenis panel | PM-OLED , OLED |
| saiz panel | 2.4 inch |
| resolusi | 240(RGB)×320 , QVGA |
| kawasan aktif | 36.72×48.96 mm |
| garis besar | 42.92×59.46×1.55 mm |
| permukaan | |
| kecerahan | 100 cd/m² (Typ.) |
| nisbah kontras | |
| warna paparan | 16.7M (8-bit), CIE193153% |
| sudut pandangan | |
| kekerapan | 60Hz |
| ic pemandu | COG Built-in DA8620 |
| antara muka isyarat | 8-bit 8080 parallel, 39 pins |
| voltan masukan | 2.8/2.8/18.0V (Typ.)(VDD/VDDIO/VCC) |
| permohonan | HHP |
