| Nombor Bahagian | DLC0090AZG |
| Jenama | Other |
| Saiz | 0.91 |
| Permohonan | HHP |
| Resolusi | 80×160 |
| Komposisi | LCM |
| Kecerahan | 100 |
| CR | 500:1 |
| Warna | |
| Lampu latar | WLED |
| Antara muka | SPI |
| jenama panel | DLC |
| model panel | DLC0090AZG |
| jenis panel | a-Si TFT-LCD , LCM |
| saiz panel | 0.91 inch |
| resolusi | 80(RGB)×160 |
| mod paparan | TN, Normally White, Transmissive |
| kawasan aktif | 11.52×20.16 mm |
| garis besar | 15.8×27×1.81 mm |
| permukaan | |
| kecerahan | 100 cd/m² (Typ.) |
| nisbah kontras | 500:1 (Typ.) |
| warna paparan | , CIE193138% |
| masa tindak balas | 10/10 (Typ.)(Tr/Td) |
| sudut pandangan | 45/45/35/45 (Typ.)(CR≥10)(L/R/U/D) |
| kekerapan | 60Hz |
| jenis lampu | 1 pcsWLEDWithout Driver |
| antara muka isyarat | 4-wire SPI, 33 pins |
| voltan masukan | 2.8V (Typ.) |
| permohonan | HHP |
