| Nombor Bahagian | AM-320240LATNQW-T00H-F |
| Jenama | AMPIRE |
| Saiz | 3.5 |
| Permohonan | HHP |
| Resolusi | 320×240 |
| Komposisi | LCM |
| Kecerahan | 400 |
| CR | 300:1 |
| Warna | 262K |
| Lampu latar | WLED |
| Antara muka | TTL |
| jenama panel | AMPIRE |
| model panel | AM-320240LATNQW-T00H-F |
| jenis panel | a-Si TFT-LCD , LCM |
| saiz panel | 3.5 inch |
| resolusi | 320(RGB)×240 , QVGA |
| mod paparan | TN, Normally White, Transmissive |
| kawasan aktif | 70.08×52.56 mm |
| garis besar | 77.8×66×5.8 mm |
| permukaan | Hard coating (3H) |
| kecerahan | 400 cd/m² (Typ.) |
| nisbah kontras | 300:1 (Typ.) |
| warna paparan | 262K (6-bit) |
| masa tindak balas | 50 (Typ.)(Tr+Td) |
| sudut pandangan | 70/70/50/70 (Typ.)(CR≥10)(L/R/U/D) |
| kekerapan | 60Hz |
| jenis lampu | 3S2PWLEDWithout Driver |
| antara muka isyarat | Parallel RGB (1 ch, 6-bit), 40 pins |
| voltan masukan | 3.3V (Typ.) |
| permohonan | HHP |
