| Nombor Bahagian | LQ043T1DG28 |
| Jenama | SHARP |
| Saiz | 4.3 |
| Permohonan | HHP |
| Resolusi | 480×272 |
| Komposisi | LCM |
| Kecerahan | 300 |
| CR | 500:1 |
| Warna | 262K |
| Lampu latar | WLED |
| Antara muka | TTL |
| jenama panel | SHARP |
| model panel | LQ043T1DG28 |
| jenis panel | a-Si TFT-LCD , LCM |
| saiz panel | 4.3 inch |
| resolusi | 480×272(RGB) , WQVGA |
| mod paparan | TN, Normally White, Transmissive |
| kawasan aktif | 95.04×53.856 mm |
| garis besar | 105.5×67.2×4.45 mm |
| permukaan | Antiglare, Hard coating (2H) |
| kecerahan | 300 cd/m² (Typ.) |
| nisbah kontras | 500:1 (Typ.) |
| warna paparan | 262K (6-bit) |
| masa tindak balas | 22/8 (Typ.)(Tr/Td) |
| sudut pandangan | 80/80/55/80 (Typ.)(CR≥10)(L/R/U/D) |
| kekerapan | 60Hz |
| jenis lampu | 9S1PWLEDWithout Driver |
| antara muka isyarat | Parallel RGB (1 ch, 6-bit) + SPI, 67 pins |
| voltan masukan | 3.3/3.3V (Typ.)(IOVCC/VCC) |
| permohonan | HHP |
| LQ043T1DG28 | SHARP | 4.3 | 480×272 |
| LQ043T1LX01A | SHARP | 4.3 | 540×960 |
| LQ043T3DX02 | SHARP | 4.3 | 480×272 |
| LQ043T3DX03 | SHARP | 4.3 | 480×272 |
| LQ043T3DX03A | SHARP | 4.3 | 480×272 |
| LQ043T3DX04 | SHARP | 4.3 | 480×272 |
| LQ043T3DX0F | SHARP | 4.3 | 480×272 |
| LQ043T3DX0G | SHARP | 4.3 | 480×272 |
| LQ043T3LX02 | SHARP | 4.3 | 480×272 |
| LQ043Y1DX01B | SHARP | 4.3 | 480×800 |
| 32NHF0H | SII | 3.2 | 360×640 |
| 32WVF0H | SII | 3.2 | 480×800 |
| A043FW03 V2 | AUO | 4.3 | 480×272 |
| COM35H3M10XTC | ORTUSTECH | 3.5 | 240×320 |
| G043FTT01.0 | AUO | 4.3 | 480×272 |
| LQ043T1DG28 | SHARP | 4.3 | 480×272 |
| TFTMD030035 | JDI | 3.0 | 640×480 |
| TM030ZDHG01 | Tianma | 3.0 | 320×320 |
| TM035HDHT1 | Tianma | 3.5 | 240×320 |
| TX09D40VM3CBA | KOE | 3.5 | 240×320 |
