| Nombor Bahagian | TX09D70VM1CEA |
| Jenama | KOE |
| Saiz | 3.5 |
| Permohonan | HHP |
| Resolusi | 240×320 |
| Komposisi | LCM |
| Kecerahan | 320 |
| CR | 300:1 |
| Warna | 262K |
| Lampu latar | WLED |
| Antara muka | TTL |
| jenama panel | HITACHI |
| model panel | TX09D70VM1CEA |
| jenis panel | a-Si TFT-LCD , LCM |
| saiz panel | 3.5 inch |
| resolusi | 240(RGB)×320 , QVGA |
| mod paparan | TN, Normally White, TMR |
| kawasan aktif | 53.64×71.52 mm |
| garis besar | 64×86×5.5 mm |
| permukaan | Antiglare, Hard coating (3H) |
| kecerahan | 320 cd/m² (Typ.) |
| nisbah kontras | 300 : 1 (Typ.) |
| warna paparan | 262K (6-bit) |
| masa tindak balas | 30 (Typ.)(Tr+Td) |
| sudut pandangan | 70/70/80/60 (Typ.)(CR≥5)(L/R/U/D) |
| kekerapan | 60Hz |
| jenis lampu | 3S2PWLEDWithout Driver |
| antara muka isyarat | CMOS (1 ch, 6-bit), 50 pins |
| voltan masukan | 3.3/8.48/15.0/-5.0V (Typ.)(DVDD/AVDD/VGH/VGL) |
| permohonan | HHP |
