| Nombor Bahagian | B101UAN02.1 |
| Jenama | AUO |
| Saiz | 10.1 |
| Permohonan | PAD |
| Resolusi | 1920×1200 |
| Komposisi | LCM |
| Kecerahan | 400 |
| CR | 800:1 |
| Warna | 16.7M |
| Lampu latar | WLED |
| Antara muka | LVDS |
| jenama panel | AUO |
| model panel | B101UAN02.1 1 Compatible model |
| jenis panel | a-Si TFT-LCD , LCM |
| saiz panel | 10.1 inch |
| resolusi | 1920(RGB)×1200 , WUXGA |
| mod paparan | AHVA, Normally Black, Transmissive |
| kawasan aktif | 216.81×135.5 mm |
| garis besar | 229.45×149.2×5 mm |
| permukaan | Glare (Haze 0%), Hard coating (3H) |
| kecerahan | 400 cd/m² (Typ.) |
| nisbah kontras | 800:1 (Typ.) |
| warna paparan | 16.7M (8-bit), CIE193168% |
| masa tindak balas | 13/12 (Typ.)(Tr/Td) |
| sudut pandangan | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| kekerapan | 60Hz |
| jenis lampu | 5 stringsWLEDWithout Driver |
| antara muka isyarat | LVDS (2 ch, 8-bit), 50 pins |
| voltan masukan | 3.3V (Typ.) |
| permohonan | PAD |
