| Nombor Bahagian | B101UAN01.7 HW1A |
| Jenama | AUO |
| Saiz | 10.1 |
| Permohonan | PAD |
| Resolusi | 1920×1200 |
| Komposisi | LCM |
| Kecerahan | 380 |
| CR | 800:1 |
| Warna | 16.7M |
| Lampu latar | WLED |
| Antara muka | MIPI |
| jenama panel | AUO |
| model panel | B101UAN01.7 HW1A |
| jenis panel | a-Si TFT-LCD , LCM |
| saiz panel | 10.1 inch |
| resolusi | 1920(RGB)×1200 , WUXGA |
| mod paparan | AHVA, Normally Black, Transmissive |
| kawasan aktif | 216.81×135.5 mm |
| garis besar | 227.72×147.8×5.35 mm |
| permukaan | Glare (Haze 0%) |
| kecerahan | 380 cd/m² (Typ.) |
| nisbah kontras | 800:1 (Typ.) |
| warna paparan | 16.7M (8-bit), CIE193150% |
| masa tindak balas | 25 (Typ.)(Tr+Td) |
| sudut pandangan | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| kekerapan | 60Hz |
| jenis lampu | WLEDEmbedded (LED Driver) |
| antara muka isyarat | MIPI (4 data lanes), 34 pins |
| voltan masukan | 3.7V (Typ.) |
| permohonan | PAD |
| B101UAN01.1 | AUO | 10.1 | 1920×1200 |
| B101UAN01.7 HW0A | AUO | 10.1 | 1920×1200 |
| B101UAN01.7 HW1A | AUO | 10.1 | 1920×1200 |
| B101UAN01.7 HW2A | AUO | 10.1 | 1920×1200 |
| B101UAN01.9 | AUO | 10.1 | 1920×1200 |
| B101UAN01.C | AUO | 10.1 | 1920×1200 |
| B101UAN01.E | AUO | 10.1 | 1920×1200 |
| B101UAN02.1 | AUO | 10.1 | 1920×1200 |
| B101UAN07.0 | AUO | 10.1 | 1200×1920 |
| B101UAN07.2 | AUO | 10.1 | 1200×1920 |
| B101EAN01.6 | AUO | 10.1 | 1280×800 |
| B101EW05 V1 | AUO | 10.1 | 1280×800 |
| BP080WX1-100 | BOE | 8.0 | 1280×800 |
| F101NWN7-0 | IVO | 10.1 | 1920×1200 |
| HSD101PUW1-A00 | HannStar | 10.1 | 1920×1200 |
| HV089WX1-100 | HYDIS | 8.9 | 1280×768 |
| HV121WX4-120 | HYDIS | 12.1 | 1280×800 |
| LP094WX1-SLA2 | LG Display | 9.4 | 1280×800 |
| LTL070NL01-002 | Samsung | 7.0 | 1024×600 |
| N101BCG-GK1 | Innolux | 10.1 | 1366×768 |
