| Nombor Bahagian | HV070WX2-100 |
| Jenama | HYDIS |
| Saiz | 7.0 |
| Permohonan | PAD |
| Resolusi | 800×1280 |
| Komposisi | LCM |
| Kecerahan | 450 |
| CR | 700:1 |
| Warna | 262K |
| Lampu latar | WLED |
| Antara muka | LVDS |
| jenama panel | HYDIS |
| model panel | HV070WX2-100 |
| jenis panel | a-Si TFT-LCD , LCM |
| saiz panel | 7.0 inch |
| resolusi | 800(RGB)×1280 , WXGA |
| mod paparan | HFFS, Normally Black, Transmissive |
| kawasan aktif | 94.2×150.72 mm |
| garis besar | 104.32×161.67×3.75 mm |
| permukaan | |
| kecerahan | 450 cd/m² (Typ.) |
| nisbah kontras | 700:1 (Typ.) |
| warna paparan | 262K (6-bit), CIE193150% |
| masa tindak balas | 30 (Typ.)(Tr+Td) |
| sudut pandangan | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| kekerapan | 60Hz |
| jenis lampu | 5S5PWLEDEmbedded (LED Driver) |
| antara muka isyarat | LVDS (1 ch, 6-bit), 31 pins |
| voltan masukan | 3.3V (Typ.) |
| permohonan | PAD |
