| Nombor Bahagian | AM1024600K7TMQW-T62H |
| Jenama | AMPIRE |
| Saiz | 7.0 |
| Permohonan | Industrial |
| Resolusi | 1024×600 |
| Komposisi | a-Si TFT-LCD , LCM |
| Kecerahan | |
| CR | 700:1 |
| Warna | 262K/16.7M |
| Lampu latar | WLED |
| Antara muka | |
| jenama panel | AMPIRE |
| saiz panel | 7.0" |
| resolusi | 1024(RGB)×600, WSVGA, 169PPI |
| kawasan paparan | 153.6(W)×90(H) mm |
| kecerahan | - |
| sudut pandangan | 75/75/70/75 (Typ.)(CR≥10) |
| pandangan terbaik pada | - |
| warna paparan | 262K/16.7M |
| kekerapan | 60Hz |
| berat badan | - |
| model panel | AM1024600K7TMQW-T62H |
| jenis panel | a-Si TFT-LCD , LCM |
| format piksel | RGB Vertical Stripe |
| pembukaan bezel | - |
| nisbah kontras | 700:1 (Typ.) (TM) |
| mod paparan | TN, Normally White, Transmissive |
| masa tindak balas | 20/20 (Typ.)(Tr/Td) |
| jenis lampu | WLED |
| skrin sentuh | PCAP |
| permohonan | Industrial |
| A070FW01 | AUO | 7.0 | 480×234 |
| C070VW02 V0 | AUO | 7.0 | 800×480 |
| EDTCB18QEF | TOSHIBA | 7.0 | 800×480 |
| G070Y2-T02 | Innolux | 7.0 | 800×480 |
| LB070WV3-SD02 | LG Display | 7.0 | 800×480 |
| LD070WX5-SM01 | LG Display | 7.0 | 900×1440 |
| LMS700JF01-001 | Samsung | 7.0 | 1024×600 |
| LQ070Y5DG20 | SHARP | 7.0 | 800×480 |
| LT070ME05000 | JDI | 7.0 | 1200×1920 |
| PM070WX9 | E Ink | 7.0 | 800×480 |
