| Nombor Bahagian | LD070WX5-SM01 |
| Jenama | LG Display |
| Saiz | 7.0 |
| Permohonan | PAD |
| Resolusi | 900×1440 |
| Komposisi | LCM |
| Kecerahan | 400 |
| CR | 800:1 |
| Warna | 16.7M |
| Lampu latar | WLED |
| Antara muka | MIPI |
| jenama panel | LG Display |
| model panel | LD070WX5-SM01 |
| jenis panel | a-Si TFT-LCD , LCM |
| saiz panel | 7.0 inch |
| resolusi | 900(RGB)×1440 , WXGA+ |
| mod paparan | IPS, Normally Black, Transmissive |
| kawasan aktif | 94.23×150.77 mm |
| garis besar | 104.85×163 mm |
| permukaan | Hard coating |
| kecerahan | 400 cd/m² (Typ.) |
| nisbah kontras | 800:1 (Typ.) |
| warna paparan | 16.7M (6-bit + Hi-FRC) |
| masa tindak balas | 35 (Typ.)(Tr+Td) |
| sudut pandangan | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| kekerapan | 60Hz |
| jenis lampu | 6S4PWLEDWithout Driver |
| antara muka isyarat | MIPI (4 data lanes), 40 pins |
| voltan masukan | 3.3V (Typ.) |
| permohonan | PAD |
