| Nombor Bahagian | LMS700JF01-001 |
| Jenama | Samsung |
| Saiz | 7.0 |
| Permohonan | MP4 |
| Resolusi | 1024×600 |
| Komposisi | LCM |
| Kecerahan | 280 |
| CR | 350:1 |
| Warna | 262K |
| Lampu latar | WLED |
| Antara muka | LVDS |
| jenama panel | SAMSUNG SMD |
| model panel | LMS700JF01-001 |
| jenis panel | a-Si TFT-LCD , LCM |
| saiz panel | 7.0 inch |
| resolusi | 1024(RGB)×600 , WSVGA |
| mod paparan | TN, Normally White, Transmissive |
| kawasan aktif | 153.6×90 mm |
| garis besar | 162.4×102×6.1 mm |
| permukaan | |
| kecerahan | 280 cd/m² (Typ.) |
| nisbah kontras | 350:1 (Typ.) |
| warna paparan | 262K (6-bit) |
| masa tindak balas | 30 (Typ.)(Tr+Td) |
| sudut pandangan | |
| kekerapan | 60Hz |
| jenis lampu | 7S3PWLEDWithout Driver |
| antara muka isyarat | LVDS (1 ch, 6-bit), 30 pins |
| voltan masukan | 3.3V (Typ.) |
| permohonan | MP4 |
