| Nombor Bahagian | VVX10F004B00 |
| Jenama | Panasonic |
| Saiz | 10.1 |
| Permohonan | PAD |
| Resolusi | 1920×1200 |
| Komposisi | LCM |
| Kecerahan | 600 |
| CR | 1000:1 |
| Warna | 16.7M |
| Lampu latar | WLED |
| Antara muka | MIPI |
| jenama panel | Panasonic |
| model panel | VVX10F004B00 1 Compatible model |
| jenis panel | a-Si TFT-LCD , LCM |
| saiz panel | 10.1 inch |
| resolusi | 1920(RGB)×1200 , WUXGA |
| mod paparan | IPS, Normally Black, Transmissive |
| kawasan aktif | 217.44×135.9 mm |
| garis besar | 228.86×152.5×4.48 mm |
| permukaan | Hard coating, Antireflection |
| kecerahan | 600 cd/m² (Min.) |
| nisbah kontras | 1000:1 (Typ.) |
| warna paparan | 16.7M (8-bit), CIE193150% |
| masa tindak balas | 30 (Typ.)(Tr+Td) |
| sudut pandangan | 80/80/80/80 (Min.)(CR≥100)(L/R/U/D) |
| kekerapan | 60Hz |
| jenis lampu | 10S6PWLEDEmbedded (LED Driver) |
| antara muka isyarat | MIPI (4 data lanes), 45 pins |
| voltan masukan | 2.5/3.3V (Typ.)(IOVDD/VDD) |
| permohonan | PAD |
