| Nombor Bahagian | LTL097QL01-W01 |
| Jenama | Samsung |
| Saiz | 9.7 |
| Permohonan | PAD |
| Resolusi | 2048×1536 |
| Komposisi | LCM |
| Kecerahan | 420 |
| CR | 1000:1 |
| Warna | 16.7M |
| Lampu latar | WLED |
| Antara muka | eDP |
| jenama panel | SAMSUNG |
| model panel | LTL097QL01-W01 1 Compatible model |
| jenis panel | a-Si TFT-LCD , LCM |
| saiz panel | 9.7 inch |
| resolusi | 2048(RGB)×1536 , QXGA |
| mod paparan | PLS, Normally Black, Transmissive |
| kawasan aktif | 196.608×147.456 mm |
| garis besar | 208.88×167.12×5.02 mm |
| permukaan | Glare (Haze 0%), Hard coating (2H), Reflection 1.45% (Max.) |
| kecerahan | 420 cd/m² (Typ.) |
| nisbah kontras | 1000:1 (Typ.) |
| warna paparan | 16.7M (8-bit) |
| masa tindak balas | 16 (Typ.)(Tr+Td) |
| sudut pandangan | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| kekerapan | 60Hz |
| jenis lampu | WLEDWithout Driver |
| antara muka isyarat | eDP (4 Lanes), 51 pins |
| voltan masukan | 3.3V (Typ.) |
| permohonan | PAD |
