| Nombor Bahagian | TX23D12VM0CAA |
| Jenama | KOE |
| Saiz | 9.0 |
| Permohonan | IA |
| Resolusi | 800×480 |
| Komposisi | LCM |
| Kecerahan | 300 |
| CR | 400:1 |
| Warna | 262K |
| Lampu latar | CCFL |
| Antara muka | TTL |
| jenama panel | HITACHI |
| model panel | TX23D12VM0CAA |
| jenis panel | a-Si TFT-LCD , LCM |
| saiz panel | 9.0 inch |
| resolusi | 800(RGB)×480 , WVGA |
| mod paparan | IPS, Normally Black, Transmissive |
| kawasan aktif | 195×117 mm |
| garis besar | 236×135 mm |
| permukaan | Antiglare |
| kecerahan | 300 cd/m² (Typ.) |
| nisbah kontras | 400:1 (Typ.) |
| warna paparan | 262K (6-bit), CIE193160% |
| masa tindak balas | 13/17 (Typ.)(Tr/Td) |
| sudut pandangan | 85/85/85/85 (Min.)(CR≥10)(L/R/U/D) |
| kekerapan | 60Hz |
| jenis lampu | 1 pcsCCFLWithout Driver |
| antara muka isyarat | CMOS (1 ch, 6-bit), 40 pins |
| voltan masukan | 3.3V (Typ.)(VDD) |
| permohonan | IA |
