| Nombor Bahagian | ZE090NA-01B |
| Jenama | Innolux |
| Saiz | 9.0 |
| Permohonan | PAD |
| Resolusi | 1280×800 |
| Komposisi | CELL |
| Kecerahan | 0 |
| CR | 700:1 |
| Warna | 16.7M |
| Lampu latar | No B/L |
| Antara muka | LVDS |
| jenama panel | CHIMEI INNOLUX |
| model panel | ZE090NA-01B |
| jenis panel | a-Si TFT-LCD , CELL |
| saiz panel | 9.0 inch |
| resolusi | 1280(RGB)×800 , WXGA |
| mod paparan | TN, Normally White, Transmissive |
| kawasan aktif | 193.92×121.2 mm |
| garis besar | 206.76×135.06×1.43 mm |
| permukaan | |
| kedalaman kaca | 0.50+0.50 mm |
| ketransmisian | 3.39% (Typ.)(with Polarizer) |
| nisbah kontras | 700:1 (Typ.) |
| warna paparan | 16.7M (8-bit), CIE193170% |
| masa tindak balas | 10/15 (Typ.)(Tr/Td) |
| sudut pandangan | 70/50/70/70 (Typ.)(CR≥10)(L/R/U/D) |
| kekerapan | 60Hz |
| antara muka isyarat | LVDS (1 ch, 6/8-bit), 40 pins |
| voltan masukan | 3.3/11.0/20.0/-6.8V (Typ.)(VDD/AVDD/VGH/VGL) |
| permohonan | PAD |
| AA090ME01 | Mitsubishi | 9.0 | 800×480 |
| CLAA090LC41CW | CPT | 9.0 | 800×480 |
| ED090NA-01H | Innolux | 9.0 | 1280×800 |
| HSD090ICW1-A00 | HannStar | 9.0 | 640×234 |
| LTA090B400F | TOSHIBA | 9.0 | 800×480 |
| NL192108AC10-01D | NLT | 9.0 | 1920×1080 |
| NL6448BC28-01 | NLT | 9.0 | 640×480 |
| T-55561D090J-LW-A-AAN | Kyocera | 9.0 | 800×480 |
| TM090JDH01 | Tianma | 9.0 | 1280×800 |
| ZE090NA-01B | Innolux | 9.0 | 1280×800 |
| BP101WX1-300 | BOE | 10.1 | 1280×800 |
| CLAA100XA22XV | CPT | 10.0 | 1024×768 |
| ED090NA-01D | Innolux | 9.0 | 1280×800 |
| HSD100PXN1-A00-C11 | HannStar | 10.0 | 1024×768 |
| HV121WX6-111 | HYDIS | 12.1 | 1280×800 |
| LP125WH2-SLB1 | LG Display | 12.5 | 1366×768 |
| LTL070NL01-002 | Samsung | 7.0 | 1024×600 |
| LTN097XL02-A01 | Samsung | 9.7 | 1024×768 |
| Q070LRE-LA1 | Innolux | 7.0 | 1024×600 |
| VVX10T022N00 | Panasonic | 10.1 | 2560×1600 |
