| Nombor Bahagian | TM070DDH09 |
| Jenama | Tianma |
| Saiz | 7.0 |
| Permohonan | MP4 |
| Resolusi | 1024×600 |
| Komposisi | LCM |
| Kecerahan | 350 |
| CR | 500:1 |
| Warna | 262K/16.7M |
| Lampu latar | WLED |
| Antara muka | LVDS |
| jenama panel | TIANMA |
| model panel | TM070DDH09 1 Compatible model |
| jenis panel | a-Si TFT-LCD , LCM |
| saiz panel | 7.0 inch |
| resolusi | 1024(RGB)×600 , WSVGA |
| mod paparan | TN, Normally White, Transmissive |
| kawasan aktif | 153.6×90 mm |
| garis besar | 167.25×104.65×2.9 mm |
| permukaan | Antiglare |
| kecerahan | 350 cd/m² (Typ.) |
| nisbah kontras | 500:1 (Typ.) |
| warna paparan | 262K/16.7M (6-bit / 6-bit + Hi-FRC), CIE193150% |
| masa tindak balas | 20 (Typ.)(Tr+Td) |
| sudut pandangan | 75/75/70/75 (Typ.)(CR≥10)(L/R/U/D) |
| kekerapan | 60Hz |
| jenis lampu | 3S6PWLEDWithout Driver |
| antara muka isyarat | LVDS (1 ch, 6/8-bit), 39 pins |
| voltan masukan | 3.3V (Typ.) |
| permohonan | MP4 |
| TM070DDH01 | Tianma | 7.0 | 1024×600 |
| TM070DDH02 | Tianma | 7.0 | 1024×600 |
| TM070DDH03 | Tianma | 7.0 | 1024×600 |
| TM070DDH07 | Tianma | 7.0 | 1024×600 |
| TM070JDHP01-00 | Tianma | 7.0 | 1280×800 |
| TM070RBH10 | Tianma | 7.0 | 800×480 |
| TM070RDH01 | Tianma | 7.0 | 800×480 |
| TM070RDH10 | Tianma | 7.0 | 800×480 |
| TM070RDH11 | Tianma | 7.0 | 800×480 |
| TM070WA-22L06 | SANYO | 7.0 | 480×234 |
| A070VW04 V0 | AUO | 7.0 | 800×480 |
| BA070WS1-400 | BOE | 7.0 | 1024×600 |
| CLAA070NB02CT | CPT | 7.0 | 1024×600 |
| CLAA070NC0DCT | CPT | 7.0 | 1024×600 |
| CLAA070ND22CW | CPT | 7.0 | 1024×600 |
| CLAA070ND28CW | CPT | 7.0 | 1024×600 |
| LMS700JF01-001 | Samsung | 7.0 | 1024×600 |
| LMS700KF21 | Samsung | 7.0 | 800×480 |
| LTP700WV-F01 | Samsung | 7.0 | 800×480 |
| TM050RBH01 | Tianma | 5.0 | 800×480 |
