| Nombor Bahagian | LTP700WV-F01 |
| Jenama | Samsung |
| Saiz | 7.0 |
| Permohonan | MP4 |
| Resolusi | 800×480 |
| Komposisi | LCM |
| Kecerahan | 350 |
| CR | 300:1 |
| Warna | 16.7M |
| Lampu latar | WLED |
| Antara muka | TTL |
| jenama panel | SAMSUNG |
| model panel | LTP700WV-F01 |
| jenis panel | a-Si TFT-LCD , LCM |
| saiz panel | 7.0 inch |
| resolusi | 800×480(RGB) , WVGA |
| mod paparan | TN, Normally White, TMR |
| kawasan aktif | 152.4×91.44 mm |
| garis besar | 163.2×104×3.6 mm |
| permukaan | |
| kecerahan | 350 cd/m² (Typ.) |
| nisbah kontras | 300 : 1 (Typ.) |
| warna paparan | 16.7M (8-bit) |
| masa tindak balas | 22.7 (Typ.)(Tr+Td) |
| sudut pandangan | 65/65/50/60 (Typ.)(CR≥10)(L/R/U/D) |
| kekerapan | 60Hz |
| jenis lampu | 8S3PWLEDWithout Driver |
| antara muka isyarat | Parallel RGB (1 ch, 8-bit), 40 pins |
| voltan masukan | 3.3V (Typ.)(VCC) |
| rohs: | |
| permohonan | MP4 |
