T420HVN08.0

T420HVN08.0
T420HVN08.0 thumb
Jenama
AUO
Saiz
42
Permohonan
LCTV
Resolusi
1920×1080
Komposisi
LCM
Kecerahan
400
CR
3000:1
Warna
16.7M
Lampu latar
WLED
Antara muka
LVDS
In Stock
367
Spesifikasi

Nombor Bahagian T420HVN08.0
JenamaAUO
Saiz42
PermohonanLCTV
Resolusi1920×1080
KomposisiLCM
Kecerahan400
CR3000:1
Warna16.7M
Lampu latarWLED
Antara mukaLVDS
jenama panelAUO
model panelT420HVN08.0
jenis panel a-Si TFT-LCD , LCM
saiz panel42 inch
resolusi1920(RGB)×1080 , FHD
mod paparanAMVA3, Normally Black, Transmissive
kawasan aktif930.24×523.26 mm
garis besar952.2×547×27.9 mm
permukaanAntiglare (Haze 2%), Hard coating (3H)
kecerahan400 cd/m² (Typ.)
nisbah kontras3000:1 (Typ.)
warna paparan16.7M (8-bit), CIE193172%
masa tindak balas6.5 (Typ.)(G to G)
sudut pandangan89/89/89/89 (Typ.)(CR≥10)(L/R/U/D)
kekerapan60Hz
jenis lampuWLEDEmbedded (LED Driver)
antara muka isyaratLVDS (2 ch, 8-bit), 51 pins
voltan masukan12.0V (Typ.)
permohonanLCTV
Model Keluarga
T420HVN01.0 AUO 42 1920×1080
T420HVN04.0 CELL AUO 42 1920×1080
T420HVN04.5 CELL AUO 42 1920×1080
T420HW01 V2 AUO 42 1920×1080
T420HW04 V0 AUO 42 1920×1080
T420HW05 V3 AUO 42 1920×1080
T420HW06 V5 AUO 42 1920×1080
T420HW07 V0 AUO 42 1920×1080
T420HW07 V1 AUO 42 1920×1080
T420HW09 V1 AUO 42 1920×1080
