LC470EUN-PFF1

LC470EUN-PFF1
LC470EUN-PFF1
LC470EUN-PFF1 thumb LC470EUN-PFF1 thumb
Jenama
LG Display
Saiz
47
Permohonan
LCTV
Resolusi
1920×1080
Komposisi
LCM
Kecerahan
350
CR
1400:1
Warna
16.7M
Lampu latar
WLED
Antara muka
LVDS
In Stock
18986
Spesifikasi

Nombor Bahagian LC470EUN-PFF1
JenamaLG Display
Saiz47
PermohonanLCTV
Resolusi1920×1080
KomposisiLCM
Kecerahan350
CR1400:1
Warna16.7M
Lampu latarWLED
Antara mukaLVDS
jenama panelLG Display
model panelLC470EUN-PFF1
jenis panel a-Si TFT-LCD , LCM
saiz panel47 inch
resolusi1920(RGB)×1080 , FHD
mod paparanIPS, Normally Black, Transmissive
kawasan aktif1039.68×584.82 mm
garis besar1059.5×609.5×31.5 mm
permukaanAntiglare (Haze 1%), Hard coating (2H)
kecerahan350 cd/m² (Typ.)
nisbah kontras1400:1 (Typ.)
warna paparan16.7M (8-bit), CIE193168%
masa tindak balas6 (Typ.)(G to G)
sudut pandangan89/89/89/89 (Min.)(CR≥10)(L/R/U/D)
kekerapan60Hz
jenis lampuWLEDEmbedded (LED Driver)
antara muka isyaratLVDS (2 ch, 8-bit), 51 pins
voltan masukan12.0V (Typ.)
permohonanLCTV
