LC470EUH-PEF1


Jenama
LG Display
Saiz
47
Permohonan
LCTV
Resolusi
1920×1080
Komposisi
LCM
Kecerahan
400
CR
1600:1
Warna
16.7M
Lampu latar
WLED
Antara muka
EPI
In Stock
14335
Spesifikasi

Nombor Bahagian LC470EUH-PEF1
JenamaLG Display
Saiz47
PermohonanLCTV
Resolusi1920×1080
KomposisiLCM
Kecerahan400
CR1600:1
Warna16.7M
Lampu latarWLED
Antara mukaEPI
jenama panelLG Display
model panelLC470EUH-PEF1
jenis panel a-Si TFT-LCD , LCM
saiz panel47 inch
resolusi1920(RGB)×1080 , FHD
mod paparanS-IPS, Normally Black, Transmissive
kawasan aktif1039.68×584.82 mm
garis besar1059.48×616.21 mm
permukaanAntiglare (Haze 1%), Hard coating (2H)
kecerahan400 cd/m² (Typ.)
nisbah kontras1600:1 (Typ.)
warna paparan16.7M (8-bit), CIE193172%
masa tindak balas8/10 (Typ.)(Tr/Td)
sudut pandangan89/89/89/89 (Min.)(CR≥10)(L/R/U/D)
kekerapan120Hz
jenis lampuWLEDWithout Driver
antara muka isyaratEPI, 100 pins
voltan masukan12.0V (Typ.)
permohonanLCTV
Model Keluarga
LC470EUD-SDM1 LG Display 47 1920×1080
LC470EUD-SEF2 LG Display 47 1920×1080
LC470EUE-SEF1 LG Display 47 1920×1080
LC470EUE-SEM2 LG Display 47 1920×1080
LC470EUF-FFP1 LG Display 47 1920×1080
LC470EUF-PFF1 LG Display 47 1920×1080
LC470EUH-PFP1 LG Display 47 1920×1080
LC470EUN-SEF1 LG Display 47 1920×1080
LC470EUN-SEM1 LG Display 47 1920×1080
LC470EUN-SEM2 LG Display 47 1920×1080
