T420HVN01.0

T420HVN01.0
T420HVN01.0
T420HVN01.0 thumb T420HVN01.0 thumb
Jenama
AUO
Saiz
42
Permohonan
LCTV
Resolusi
1920×1080
Komposisi
LCM
Kecerahan
350
CR
3000:1
Warna
16.7M
Lampu latar
WLED
Antara muka
LVDS
In Stock
14857
Spesifikasi

Nombor Bahagian T420HVN01.0
JenamaAUO
Saiz42
PermohonanLCTV
Resolusi1920×1080
KomposisiLCM
Kecerahan350
CR3000:1
Warna16.7M
Lampu latarWLED
Antara mukaLVDS
jenama panelAUO
model panelT420HVN01.0
jenis panel a-Si TFT-LCD , LCM
saiz panel42 inch
resolusi1920(RGB)×1080 , FHD
mod paparanAMVA, Normally Black, Transmissive
kawasan aktif930.24×523.26 mm
garis besar960.4×560.4 mm
permukaanAntiglare (Haze 2%), Hard coating (3H)
kecerahan350 cd/m² (Typ.)
nisbah kontras3000:1 (Typ.)
warna paparan16.7M (8-bit), CIE193172%
masa tindak balas6.5 (Typ.)(G to G)
sudut pandangan89/89/89/89 (Typ.)(CR≥10)(L/R/U/D)
kekerapan60Hz
jenis lampuWLEDEmbedded (LED Driver)
antara muka isyaratLVDS (2 ch, 8-bit), 51 pins
voltan masukan12.0V (Typ.)
permohonanLCTV
Model Keluarga
T420HVN01.1 AUO 42 1920×1080
T420HVN01.1 CELL AUO 42 1920×1080
T420HVN02.0 AUO 42 1920×1080
T420HVN04.5 CELL AUO 42 1920×1080
T420HVN05.2 AUO 42 1920×1080
T420HW01 V2 AUO 42 1920×1080
T420HW02 V0 AUO 42 1920×1080
T420HW07 V4 AUO 42 1920×1080
T420HW07 V5 AUO 42 1920×1080
T420HW07 V7 AUO 42 1920×1080
