| Nombor Bahagian | SVA101WV1(01TA)(A) |
| Jenama | SVA-NEC |
| Saiz | 10.0 |
| Permohonan | NOPC |
| Resolusi | 1024×576 |
| Komposisi | LCM |
| Kecerahan | 200 |
| CR | 400:1 |
| Warna | 262K |
| Lampu latar | WLED |
| Antara muka | LVDS |
| jenama panel | SVA-NEC |
| model panel | SVA101WV1(01TA)(A) |
| jenis panel | a-Si TFT-LCD , LCM |
| saiz panel | 10.0 inch |
| resolusi | 1024(RGB)×576 , WSVGA |
| mod paparan | TN, Normally White, Transmissive |
| kawasan aktif | 221.184×124.416 mm |
| garis besar | 235×143×5.2 mm |
| permukaan | Antiglare, Hard coating (3H) |
| kecerahan | 200 cd/m² (Typ.) |
| nisbah kontras | 400:1 (Typ.) |
| warna paparan | 262K (6-bit), CIE193145% |
| masa tindak balas | 8 (Typ.)(Tr+Td) |
| sudut pandangan | 45/45/15/35 (Typ.)(CR≥10)(L/R/U/D) |
| kekerapan | 60Hz |
| jenis lampu | WLEDEmbedded (LED Driver) |
| antara muka isyarat | LVDS (1 ch, 6-bit), 40 pins |
| voltan masukan | 3.3V (Typ.) |
| permohonan | NOPC |
| HSD100PXN1-A00 | HannStar | 10.0 | 1024×768 |
| HSD100PXN1-A00-C11 | HannStar | 10.0 | 1024×768 |
| LM100SS1T522 | SHARP | 10.0 | 800×600 |
| LT100AA40000 | TOSHIBA | 10.0 | 800×600 |
| PM100WX2 | E Ink | 10.0 | 800×480 |
| PW100XS1 | E Ink | 10.0 | 640×468 |
| PW100XS5 | E Ink | 10.0 | 640×468 |
| SVA101WV1(01TA)(A) | SVA-NEC | 10.0 | 1024×576 |
| SX25S004 | KOE | 10.0 | 800×600 |
| TM100SV-A02-01 | SANYO | 10.0 | 800×600 |
| A089SW01 V0 | AUO | 8.9 | 1024×600 |
| AT102TN42 | Innolux | 10.2 | 1024×600 |
| B116XTN02.3 HW0A | AUO | 11.6 | 1366×768 |
| BA101WS1-100 | BOE | 10.1 | 1024×600 |
| CLAA101NB03A | CPT | 10.1 | 1024×600 |
| LP101WS1-TLB1 | LG Display | 10.1 | 1024×576 |
| LP116WH1-TLN1 | LG Display | 11.6 | 1366×768 |
| M101NWT2 R2 | IVO | 10.1 | 1024×600 |
| N101L6-L0C | Innolux | 10.1 | 1024×600 |
| N116BGE-L32 | Innolux | 11.6 | 1366×768 |
