| Nombor Bahagian | PW100XS1 |
| Jenama | E Ink |
| Saiz | 10.0 |
| Permohonan | CNS |
| Resolusi | 640×468 |
| Komposisi | LCM |
| Kecerahan | 350 |
| CR | 350:1 |
| Warna | Full color |
| Lampu latar | CCFL |
| Antara muka | Analog |
| jenama panel | PVI |
| model panel | PW100XS1 |
| jenis panel | a-Si TFT-LCD , LCM |
| saiz panel | 10.0 inch |
| resolusi | 640(RGB)×468 |
| mod paparan | TN, Normally White, Transmissive |
| kawasan aktif | 216×129.636 mm |
| garis besar | 235×145.8×6.4 mm |
| permukaan | Antiglare |
| kecerahan | 350 cd/m² (Typ.) |
| nisbah kontras | 350:1 (Typ.) |
| warna paparan | Full color |
| masa tindak balas | 15/25 (Typ.)(Tr/Td) |
| sudut pandangan | 50/50/15/35 (Typ.)(CR≥10)(L/R/U/D) |
| jenis lampu | 1 pcsCCFLWithout Driver |
| antara muka isyarat | TFT Specific Analog RGB, 32 pins |
| voltan masukan | 3.3/3.3/13.0/20.0/-8.0V (VCC/VDD1/VDD2/VGH/VEE) |
| permohonan | CNS |
| AT102TN03 V.8 | Innolux | 10.2 | 800×480 |
| C065GW02 V1 | AUO | 6.5 | 400×234 |
| C080VW04 V0 | AUO | 8.0 | 800×480 |
| CLAA070LC05CW | CPT | 7.0 | 800×480 |
| CLAA088WA01XN | CPT | 8.8 | 1280×480 |
| L5F30947T0A | Epson | 6.5 | 800×480 |
| LQ050T5DG01 | SHARP | 5.0 | 400×240 |
| LQ080Y5DG03 | SHARP | 8.0 | 800×480 |
| LTA065B626A | TOSHIBA | 6.5 | 400×234 |
| PA080XS2 | E Ink | 7.9 | 480×468 |
