| Nombor Bahagian | PW100XS5 |
| Jenama | E Ink |
| Saiz | 10.0 |
| Permohonan | CNS |
| Resolusi | 640×468 |
| Komposisi | LCM |
| Kecerahan | 350 |
| CR | 350:1 |
| Warna | Full color |
| Lampu latar | CCFL |
| Antara muka | Analog |
| jenama panel | PVI |
| model panel | PW100XS5 |
| jenis panel | a-Si TFT-LCD , LCM |
| saiz panel | 10.0 inch |
| resolusi | 640(RGB)×468 |
| mod paparan | TN, Normally White, Transmissive |
| kawasan aktif | 216×129.636 mm |
| garis besar | 235×145.8×6.4 mm |
| permukaan | Antiglare |
| kecerahan | 350 cd/m² (Typ.) |
| nisbah kontras | 350:1 (Typ.) |
| warna paparan | Full color |
| masa tindak balas | 15/25 (Typ.)(Tr/Td) |
| sudut pandangan | 50/50/15/35 (Typ.)(CR≥10)(L/R/U/D) |
| kekerapan | 60Hz |
| jenis lampu | 1 pcsCCFLWithout Driver |
| antara muka isyarat | TFT Specific Analog RGB, 32 pins |
| voltan masukan | 3.3/5.0/12.5/24.0/-8.0V (Typ.)(VCC/VDD2/VDD1/VGH/VEE) |
| permohonan | CNS |
