| Nombor Bahagian | PM100WX2 |
| Jenama | E Ink |
| Saiz | 10.0 |
| Permohonan | CNS |
| Resolusi | 800×480 |
| Komposisi | LCM |
| Kecerahan | 350 |
| CR | 400:1 |
| Warna | 262K |
| Lampu latar | CCFL |
| Antara muka | TTL |
| jenama panel | PVI |
| model panel | PM100WX2 |
| jenis panel | a-Si TFT-LCD , LCM |
| saiz panel | 10.0 inch |
| resolusi | 800(RGB)×480 , WVGA |
| mod paparan | TN, Normally White, Transmissive |
| kawasan aktif | 216×129.6 mm |
| garis besar | 232×144.3×6.5 mm |
| permukaan | Antiglare |
| kecerahan | 350 cd/m² (Typ.) |
| nisbah kontras | 400:1 (Typ.) |
| warna paparan | 262K (6-bit) |
| masa tindak balas | 15/25 (Typ.)(Tr/Td) |
| sudut pandangan | 50/50/15/35 (Typ.)(CR≥10)(L/R/U/D) |
| kekerapan | 60Hz |
| jenis lampu | 1 pcsCCFLWithout Driver |
| antara muka isyarat | Parallel RGB (1 ch, 6-bit), 60 pins |
| voltan masukan | 3.3/3.3/9.5/27.0/-10.0V (Typ.)(VCC/VDD/VDD2/VGH/VEE) |
| permohonan | CNS |
