| Nombor Bahagian | P101DEA-AZ0 |
| Jenama | Innolux |
| Saiz | 10.1 |
| Permohonan | Pad & Tablet |
| Resolusi | 800×1280 |
| Komposisi | LCM, a-Si TFT-LCD |
| Kecerahan | |
| CR | 1000:1 |
| Warna | 16.7M |
| Lampu latar | 4 |
| Antara muka | MIPI |
| pengilang | Innolux |
| nama model | P101DEA-AZ0 |
| saiz skrin | 10.1 inch |
| jenis skrin | LCM, a-Si TFT-LCD |
| nombor piksel | 800(RGB)×1280 (WXGA) 150PPI |
| susunan | RGB Vertical Stripe |
| kawasan aktif (mm) | 135.36 × 216.576 (H×V) |
| garis besar (mm) | 143.24 × 229.18 × 4.4 (H×V×D) |
| kawasan bezel (mm) | - |
| rawatan | Glare (Haze 0%), Hard coating |
| kecerahan | 500 cd/m² (Typ.) |
| nisbah kontras | 1000 : 1 (Typ.) (TM) |
| sudut pandangan | 80/80/80/80 (Min.)(CR≥10) |
| tindak balas | 35 (Max.)(Tr+Td) ms |
| pandangan yang baik di | Symmetry |
| mod kerja | AAS, Normally Black, Transmissive |
| kedalaman warna | 16.7M 60% NTSC |
| lampu latar | 4 strings WLED , 15K hours , No Driver |
| jisim | 175g (Max.) |
| digunakan untuk | Pad & Tablet |
| kadar segar semula | 60Hz |
| skrin sentuh | Without |
| jenis isyarat | MIPI (4 data lanes) , Connector 40 pins |
| bekalan voltan | 1.8/5.0/-5.0V (Typ.)(VDDI/AVDD/AVEE) |
| maks. penilaian | Storage Temp.: -30 ~ 70 °C Operating Temp.: -10 ~ 60 °C |
