OEL9M0083-G-E

OEL9M0083-G-E
OEL9M0083-G-E thumb
Jenama
Other
Saiz
0.96
Permohonan
Resolusi
128×64
Komposisi
OLED
Kecerahan
CR
10000:1
Warna
Mono(Green)
Lampu latar
self
Antara muka
CPU/SPI/I²C
In Stock
13185
Spesifikasi

Nombor Bahagian OEL9M0083-G-E
JenamaOther
Saiz0.96
Permohonan
Resolusi128×64
KomposisiOLED
Kecerahan
CR10000:1
WarnaMono(Green)
Lampu latarself
Antara mukaCPU/SPI/I²C
jenama panelTRULY
model panelOEL9M0083-G-E
jenis panel PM-OLED , OLED
saiz panel0.96 inch
resolusi128×64
kawasan aktif21.74×11.175 mm
garis besar26.7×19.26×1.65 mm
permukaan
kecerahan
nisbah kontras10000 : 1 (Min.)
warna paparanMono(Green) (1-bit)
sudut pandangan80/80/80/80 (Min.)(L/R/U/D)
kekerapan100Hz
ic pemanduCOG Built-in SH1106G
antara muka isyarat8-bit 6800/8080 parallel, 3/4-wire SPI, I²C, 30 pins
