| Nombor Bahagian | C-51505NFQJ-LW-ALN |
| Jenama | Kyocera |
| Saiz | 3.0 |
| Permohonan | |
| Resolusi | 20×2 |
| Komposisi | LCM |
| Kecerahan | |
| CR | 80:1 |
| Warna | Monochrome |
| Lampu latar | WLED |
| Antara muka | CPU |
| jenama panel | Kyocera |
| model panel | C-51505NFQJ-LW-ALN 1 Compatible model |
| jenis panel | FSTN-LCD , LCM |
| saiz panel | 3.0 inch |
| format paparan | 20 characters × 2 lines |
| mod paparan | STN, Black/White (Negative), Transmissive |
| paparan fon | 5×8 dots |
| saiz watak | 3.235×5.585 mm |
| nada watak | 3.8×5.95 mm |
| kawasan aktif | 75.435×11.535 mm |
| kawasan bezel | 83.0×18.6 mm |
| garis besar | 116×37×15.9 mm |
| kecerahan | |
| nisbah kontras | 80:1 (Typ.) |
| warna paparan | Monochrome |
| masa tindak balas | 45/200 (Typ.)(Tr/Td) |
| jenis lampu | 1 pcsWLEDWithout Driver |
| antara muka isyarat | 8-bit parallel, 16 pins |
| voltan masukan | 5.0V (Typ.) |
