OEL9M0039-W-E

OEL9M0039-W-E
OEL9M0039-W-E thumb
Jenama
Other
Saiz
1.5
Permohonan
MPH
Resolusi
128×128
Komposisi
OLED
Kecerahan
35
CR
10000:1
Warna
Grayscale(W)
Lampu latar
self
Antara muka
CPU/SPI
In Stock
8244
Spesifikasi

Nombor Bahagian OEL9M0039-W-E
JenamaOther
Saiz1.5
PermohonanMPH
Resolusi128×128
KomposisiOLED
Kecerahan35
CR10000:1
WarnaGrayscale(W)
Lampu latarself
Antara mukaCPU/SPI
jenama panelTRULY
model panelOEL9M0039-W-E
jenis panel PM-OLED , OLED
saiz panel1.5 inch
resolusi128×128
kawasan aktif26.86×26.86 mm
garis besar34.9×37.8×1.6 mm
permukaan
kecerahan35 cd/m² (Typ.)
nisbah kontras10000 : 1 (Min.)
warna paparanGrayscale(W) (4-bit)
sudut pandangan80/80/80/80 (Min.)(L/R/U/D)
kekerapan100Hz
ic pemanduCOG Built-in SSD1329Z
antara muka isyarat8-bit 6800/8080 parallel, SPI, 25 pins
voltan masukan3.0/3.0/15.0V (Typ.)(VDD/VDDIO/VCC)
permohonanMPH
Model Keluarga
OEL9M0039-B-E Other 1.5 128×128
OEL9M0039-G-E Other 1.5 128×128
OEL9M0039-W-E Other 1.5 128×128
OEL9M0064-B-E Other 2.0 128×32
OEL9M0064-Y-E Other 2.0 128×32
OEL9M0072-B-E Other 1.54 128×64
OEL9M0073-W-E Other 1.0 128×64
OEL9M0073-Y-E Other 1.0 128×64
OEL9M0083-B-E Other 0.96 128×64
OEL9M0083-R-E Other 0.96 128×64
