| Nombor Bahagian | LW700AT9009 |
| Jenama | Innolux |
| Saiz | 7.0 |
| Permohonan | MP4 |
| Resolusi | 800×480 |
| Komposisi | LCM |
| Kecerahan | 250 |
| CR | 400:1 |
| Warna | 16.7M |
| Lampu latar | WLED |
| Antara muka | TTL |
| jenama panel | ChiHsin |
| model panel | LW700AT9009 |
| jenis panel | a-Si TFT-LCD , LCM |
| saiz panel | 7.0 inch |
| resolusi | 800(RGB)×480 , WVGA |
| mod paparan | TN, Normally White, Transmissive |
| kawasan aktif | 152.4×91.44 mm |
| garis besar | 165×104.4×5.5 mm |
| permukaan | Antiglare |
| kecerahan | 250 cd/m² (Typ.) |
| nisbah kontras | 400:1 (Typ.) |
| warna paparan | 16.7M (8-bit), CIE193145% |
| masa tindak balas | 5/15 (Typ.)(Tr/Td) |
| sudut pandangan | 70/70/60/70 (Typ.)(CR≥10)(L/R/U/D) |
| kekerapan | 60Hz |
| jenis lampu | 3S5PWLEDWithout Driver |
| antara muka isyarat | TTL (1 ch, 8-bit), 60 pins |
| voltan masukan | 3.3/12.0/18.0/-7.0V (Typ.)(Vcc/AVDD/VGH/VGL) |
| permohonan | MP4 |
