LG Display LP101WH4-SLAF lembaran data, spesifikasi, stok, aplikasi www.looklcd-my.com
LookLCD LookLCD


LP101WH4-SLAF

LP101WH4-SLAF
LP101WH4-SLAF thumb
Jenama
LG Display
Saiz
10.1
Permohonan
PAD
Resolusi
1366×768
Komposisi
LCM
Kecerahan
CR
800:1
Warna
16.7M
Lampu latar
WLED
Antara muka
LVDS
In Stock
10737
Spesifikasi

Nombor Bahagian LP101WH4-SLAF
JenamaLG Display
Saiz10.1
PermohonanPAD
Resolusi1366×768
KomposisiLCM
Kecerahan
CR800:1
Warna16.7M
Lampu latarWLED
Antara mukaLVDS
jenama panelLG Display
model panelLP101WH4-SLAF
jenis panel a-Si TFT-LCD , LCM
saiz panel10.1 inch
resolusi1366(RGB)×768 , WXGA
mod paparanIPS, Normally Black, Transmissive
kawasan aktif222.52×125.11 mm
permukaan
kecerahan
nisbah kontras800:1 (Typ.)
warna paparan16.7M (8-bit)
masa tindak balas25 (Typ.)(Tr+Td)
sudut pandangan85/85/85/85 (Typ.)(CR≥10)(L/R/U/D)
kekerapan60Hz
jenis lampuWLEDWithout Driver
antara muka isyaratLVDS (1 ch, 8-bit)
voltan masukan3.3V (Typ.)
permohonanPAD
Model Keluarga
LP101WH1-TLA3 LG Display 10.1 1366×768
LP101WH1-TLB1 LG Display 10.1 1366×768
LP101WH1-TLP1 LG Display 10.1 1366×768
LP101WH4-SLP2 LG Display 10.1 1366×768
LP101WS1-TLA1 LG Display 10.1 1024×576
LP101WS1-TLB1 LG Display 10.1 1024×576
LP101WS1-TLB2 LG Display 10.1 1024×576
LP101WSA-TLB1 LG Display 10.1 1024×600
LP101WSA-TLN1 LG Display 10.1 1024×600
LP101WX2-SLA1 LG Display 10.1 1280×800
