| Nombor Bahagian | A065VL01 V2 |
| Jenama | AUO |
| Saiz | 6.5 |
| Permohonan | MP4 |
| Resolusi | 800×480 |
| Komposisi | LCM |
| Kecerahan | 250 |
| CR | 250:1 |
| Warna | 262K |
| Lampu latar | WLED |
| Antara muka | TTL |
| jenama panel | AUO |
| model panel | A065VL01 V2 |
| jenis panel | LTPS TFT-LCD , LCM |
| saiz panel | 6.5 inch |
| resolusi | 800(RGB)×480 , WVGA |
| mod paparan | TN, Normally White, Transmissive |
| kawasan aktif | 143.4×79.2 mm |
| garis besar | 157.2×89.2 mm |
| permukaan | Antiglare (Haze 8%) |
| kecerahan | 250 cd/m² (Typ.) |
| nisbah kontras | 250:1 (Typ.) |
| warna paparan | 262K (6-bit) |
| masa tindak balas | 12/18 (Typ.)(Tr/Td) |
| sudut pandangan | 55/55/45/60 (Typ.)(CR≥10)(L/R/U/D) |
| jenis lampu | 4S1PWLEDWithout Driver |
| antara muka isyarat | Parallel RGB (1 ch, 6-bit), 80 pins |
| voltan masukan | 3.3/10.5/13.5/-7V (Typ.)(VCC/AVDD/VGH/VGL) |
| permohonan | MP4 |
