| Nombor Bahagian | AM-1024600-070H |
| Jenama | Other |
| Saiz | 7.0 |
| Permohonan | CNS |
| Resolusi | 1024×600 |
| Komposisi | LCM |
| Kecerahan | |
| CR | |
| Warna | 262K/16.7M |
| Lampu latar | WLED |
| Antara muka | LVDS |
| jenama panel | Amson |
| model panel | AM-1024600-070H |
| jenis panel | a-Si TFT-LCD , LCM |
| saiz panel | 7.0 inch |
| resolusi | 1024(RGB)×600 , WSVGA |
| mod paparan | TN, Normally White, Transmissive |
| kawasan aktif | 153.6×90 mm |
| garis besar | 165.75×105.39×3.7 mm |
| permukaan | |
| kecerahan | |
| nisbah kontras | |
| warna paparan | 262K/16.7M (6-bit / 6-bit + Dithering) |
| masa tindak balas | |
| sudut pandangan | |
| kekerapan | 60Hz |
| jenis lampu | WLEDWithout Driver |
| antara muka isyarat | LVDS (1 ch, 6/8-bit), 40 pins |
| voltan masukan | 3.3V (Typ.) |
| permohonan | CNS |
