| Nombor Bahagian | AT070TN83 |
| Jenama | Innolux |
| Saiz | 7.0 |
| Permohonan | MP4 |
| Resolusi | 800×480 |
| Komposisi | LCM |
| Kecerahan | 300 |
| CR | 500:1 |
| Warna | 262K |
| Lampu latar | WLED |
| Antara muka | TTL |
| jenama panel | INNOLUX |
| model panel | AT070TN83 0 Compatible model |
| jenis panel | a-Si TFT-LCD , LCM |
| saiz panel | 7.0 inch |
| resolusi | 800(RGB)×480 , WVGA |
| mod paparan | TN, Normally White, Transmissive |
| kawasan aktif | 152.4×91.44 mm |
| garis besar | 165×104×5.8 mm |
| permukaan | Antiglare |
| kecerahan | 300 cd/m² (Typ.) |
| nisbah kontras | 500:1 (Typ.) |
| warna paparan | 262K (6-bit) |
| masa tindak balas | 10/15 (Typ.)(Tr/Td) |
| sudut pandangan | 70/70/50/70 (Typ.)(CR≥10)(L/R/U/D) |
| jenis lampu | 3S9PWLEDWithout Driver |
| antara muka isyarat | TTL (1 ch, 6-bit), 40 pins |
| voltan masukan | 3.3V (Typ.)(VCC) |
| permohonan | MP4 |
