| Nombor Bahagian | HT10X21-311 |
| Jenama | HYDIS |
| Saiz | 10.4 |
| Permohonan | PAD |
| Resolusi | 1024×768 |
| Komposisi | LCM |
| Kecerahan | 170 |
| CR | 500:1 |
| Warna | 262K |
| Lampu latar | CCFL |
| Antara muka | LVDS |
| jenama panel | BOE HYDIS |
| model panel | HT10X21-311 |
| jenis panel | a-Si TFT-LCD , LCM |
| saiz panel | 10.4 inch |
| resolusi | 1024(RGB)×768 , XGA |
| mod paparan | FFS, Normally Black, Transmissive |
| kawasan aktif | 210.4×157.8 mm |
| garis besar | 238.6×173.2 mm |
| permukaan | Antiglare (Haze 25%), Hard coating (3H) |
| kecerahan | 170 cd/m² (Typ.) |
| nisbah kontras | 500:1 (Typ.) |
| warna paparan | 262K (6-bit), CIE193145% |
| masa tindak balas | 40 (Typ.)(Tr+Td) |
| sudut pandangan | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| kekerapan | 60Hz |
| jenis lampu | 1 pcsCCFLWithout Driver |
| antara muka isyarat | LVDS (1 ch, 6-bit), 14 pins |
| voltan masukan | 3.3V (Typ.) |
| permohonan | PAD |
